Providing sophisticated analytical tools to advance research & product development and quality in the Nanotechnology industry
Extrad Instrumentation Serves To Provide The Most Advanced Technologies In Electron Microscopy Ranging From State of The Art Imaging Solution, Software and Accessories as well as Sample Preparation Tools to The Continually Evolving ASEAN Market
Our Products
Events & Happenings
Wednesday, March 27th
10.00am CET (5.00pm GMT+8)
Upcoming Exhibition: IPFA 2024 Booth a22.
15th – 18th July 2024
Our Strategic Partners
Gatan
Galan, Inc. is the world’s leading manufacturer of instrumentation and software used to enhance and extend the operation and performance of electron microscopes. Gatan is the recognized leader in the industry and our products set the industry standards. Our designers and engineers understand the application criteria of our customers and provide them with the right solutions for their application needs.
Kleindiek Nanotechnik
With more than 20 years of innovation, Kleindiek Nanotechnik is a leading supplier of nano-manipulation products for electron and light microscopy. Due to miniaturisation in semiconductor technology, optics, micro-mechanics, medicine, gene- and bio-technology, highly precise positioning techniques are becoming increasingly important. Our products offer customers in semi-conductor, material science and life science a new level of precision.
DENSsolutions
DENSsolutions has been at the forefront of the in situ TEM microscopy field for more than 20 years. In the process they have developed the most innovative and leading sample management solutions i.e. TEM platforms. These solutions extend the capabilities of a conventional TEM to a controllable and powerful in situ nano-laboratory. This has been made possible by combining expertise from fields including microscopy, physics, chemistry, engineering and other specialty areas.
Emcrafts’s SEM is widely used across various fields to produce unprecedented images of the microscopic and nanometric world.
Our family of SEM models are widely-used in research fields and industry applications such as semiconductor,flat-panel display, and nanotechnology labs .
- Quality control of electronics circuits and semiconductor parts
- Observation of microstructure of Secondary cell, CNT (Carbon Nano Tube), Solar Cell, Wafer, Bonding Wire, LED,Nano tech
3D-Micromac AG is the industry leader in laser micromachining and delivers powerful, user- friendly and leading-edge processes with superior production efficiency.
3D-Micromac develops processes, machines and turnkey solutions at the highest technical and technological level. The microPREPTM PRO enables laser-based sample preparation for a variety of specimen preparation applications. With its integrated ultrashort pulsed laser source, it complements existing approaches to sample preparation such as ion beam processing. microPREPTM PRO is suited to ablate metals, semiconductors, ceramics, polymers, and compound materials. It creates new vistas for material and process development as well as failure analysis
